Milling · Fräsen
Solid Carbide end mills · Vollhartmetallschaftfräser
HM-4B series for machining high hardness steel · HM-4B Serie für die Hartbearbeitung
4-flute ball nose mills with long straight shank 4-Schneiden Kugelkopffräser mit Zylinderschaft
R
A
R
B
10°
L
H
L
H
35o
Coated
Nano-AITiN
D D≤12 0~-0.020 12<D 0~-0.030
R R±0.01
Type
Typ
Dimension(mm)
Abmessungen
Teeth
Zähne
Z
Geometry
Ausführung
Grade
Sorte
KMG 555
D
R
d
H
L
HM-4B-R1.5 HM-4B-R2.5 HM-4B-R4.0 HM-4B-R6.0 HM-4B-R8.0 HM-4B-R10.0
3.0 1.5
5.0 2.5 6.0 10.0 8.0 4.0 8.0 16.0
12.0 6.0 12.0 24.0 16.0 8.0 16.0 32.0 20.0 10.0 20.0 40.0
4 A ● A ●
6.0 6.0 50
50 4
B
HM-4B-R2.0
4.0
2.0
6.0
8.0
50
4
A
●
HM-4B-R3.0
6.0
3.0
6.0
12.0
50
4
B
●
Material Overview · Material Übersicht
