Milling · Fräsen
Solid Carbide end mills · Vollhartmetallschaftfräser
AL-2RL-AIR series for machining aluminium · AL-2RL-AIR Serie für die Bearbeitung von Aluminium
2-flute radius end mills with long straight shank 2-Schneiden Radiusfräser mit langem Zylinderschaft
Ultrahigh speed
HSC
B
Dimension(mm)
Abmessungen
Teeth Grade
Zähne Sorte
Z YK40F
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
2 ○
30o
D D≤12 0~-0.020 12<D 0~-0.030
Type
Typ
AL-2RL-D6.0R1.0- AIR
AL-2RL-D8.0R1.0- AIR
AL-2RL-D10.0R1.0- AIR
AL-2RL-D10.0R2.0- AIR
AL-2RL-D12.0R1.0- AIR
AL-2RL-D12.0R2.0- AIR
AL-2RL-D12.0R3.0- AIR
AL-2RL-D16.0R1.0- AIR
AL-2RL-D16.0R2.0- AIR
AL-2RL-D16.0R3.0- AIR
AL-2RL-D16.0R4.0- AIR
AL-2RL-D20.0R1.0- AIR
AL-2RL-D20.0R2.0- AIR
AL-2RL-D20.0R3.0- AIR
AL-2RL-D20.0R4.0- AIR
AL-2RL-D20.0R5.0- AIR
AL-2RL-D20.0R6.0- AIR
D R d d1
H M L
6 1.0
8 1.0
10 1.0
10 2.0
12 1.0
12 2.0
12 3.0
16 1.0
16 2.0
16 3.0
16 4.0
20 1.0
20 2.0
20 3.0
20 4.0
20 5.0
20 6.0
6 5.5 7
8 7.4 9
10 9.2 11
10 9.2 11
12 11 12
12 11 12
12 11 12
16 15 16
16 15 16
16 15 16
16 15 16
20 19 20
20 19 20
20 19 20
20 19 20
20 19 20
20 19 20
43 80
53 90
59 100
59 100
74 120
74 120
74 120
84 140
84 140
84 140
84 140
89 140
89 140
89 140
89 140
89 140
89 140
for air space industry ∙ für Luft- und Raumfahrt - Industrie
Material Overview · Material Übersicht
● Ex Stock / ab Lager ○ On demand / auf Anfrage
= Very suitable · Sehr empfohlen = Suitable · Empfohlen
Workpiece material
Werkstückstoff
Carbon steel Kohlenstoff Stahl
Alloy steel
Legierter Stahl
Quenched and tempered steel · Vergüteter Stahl
Hardened steel ·
Gehärteter Stahl
Stainless steel · Rostfreier Stahl
Cast iron, Nodular cast iron Grauguss GGG
Copper alloy Kupfer Leg
Aluminum alloy Alu Leg
Titanium alloy Titan Leg
Heat resist alloy warmfeste Leg
~40HRC
~50HRC
~60HRC
~68HRC
B 366
YK 40F
Solid Carbide end mills
Vollhartmetallschaftfräser
