Page 127 - Bohren Komplettprogramm

ZTD03
3D
Drilling · Bohren Indexable drill · Wendeschneidplattenbohrer
3
Screw Wrench
Schraube Schlüssel
I60M2.0×4.3 WT06IP I60M2.0×4.3 WT06IP I60M2.0×4.3 WT06IP I60M2.0×4.3 WT06IP I60M2.2×5.5 WT07IP I60M2.2×5.5 WT07IP I60M2.2×5.5 WT07IP I60M2.2×5.5 WT07IP I60M2.2×5.5 WT07IP I60M2.2×5.5 WT07IP I60M2.5×6.5 WT07IP I60M2.5×6.5 WT07IP I60M2.5×6.5 WT07IP I60M2.5×6.5 WT07IP I60M2.5×6.5 WT07IP I60M2.5×6.5 WT07IP I60M2.5×6.5 WT07IP
I60M3.5×8 WT15IP I60M3.5×8 WT15IP I60M3.5×8 WT15IP I60M3.5×8 WT15IP I60M3.5×8 WT15IP I60M3.5×8 WT15IP I60M3.5×8 WT15IP I60M4×10 WT15IP I60M4×10 WT15IP I60M4×10 WT15IP I60M4×10 WT15IP I60M4×10 WT15IP I60M4×10 WT15IP I60M4×10 WT15IP I60M5×13 WT20IP I60M5×13 WT20IP I60M5×13 WT20IP I60M5×13 WT20IP I60M5×13 WT20IP I60M5×13 WT20IP I60M5×13 WT20IP
Type Stock
Typ Lager ØD
Dimension
Abmessung (mm)
ØD1 ØD2 L3 L2 L1 L 20 25 50 67 44 111
20 25 50 67 47 114 20 25 50 64 50 114 20 25 50 67 53 120 25 32 56 79 56 135 25 32 56 82 59 138 25 32 56 84 62 140 25 32 56 87 65 143 25 32 56 90 68 146 25 32 56 93 71 149 25 40 56 96 74 153 25 40 56 102 77 159 25 40 56 102 80 159 25 40 56 105 83 162 25 40 56 108 86 165 25 40 56 111 89 168 32 45 60 117 92 178 32 45 60 120 95 181 32 45 60 123 98 184 32 45 60 126 101 187 32 45 60 129 104 190 32 45 60 132 107 193 32 45 60 135 110 196 32 45 60 138 113 199 40 55 70 147 117 217 40 55 70 150 119 220 40 55 70 153 122 223 40 55 70 160 125 231 40 55 70 158 128 229 40 55 70 161 131 232 40 55 70 169 134 240 40 60 70 178 138 248 40 60 70 181 141 251 40 60 70 184 144 254 40 60 70 187 147 257 40 60 70 189 149 260 40 60 70 192 152 263 40 60 70 195 155 266
Insert
WSP
SPGT050204-PM/PE SPGT050204-PM/PE SPGT050204-PM/PE SPGT050204-PM/PE SPGT060204-PM/EM SPGT060204-PM/EM SPGT060204-PM/EM SPGT060204-PM/EM SPGT060204-PM/EM SPGT060204-PM/EM SPGT07T308-PM/EM SPGT07T308-PM/EM SPGT07T308-PM/EM SPGT07T308-PM/EM SPGT07T308-PM/EM SPGT07T308-PM/EM SPGT07T308-PM/EM SPGT090408-PM/EM SPGT090408-PM/EM SPGT090408-PM/EM SPGT090408-PM/EM SPGT090408-PM/EM SPGT090408-PM/EM SPGT090408-PM/EM SPGT110408-PM/EM SPGT110408-PM/EM SPGT110408-PM/EM SPGT110408-PM/EM SPGT110408-PM/EM SPGT110408-PM/EM SPGT110408-PM/EM SPGT140512-PM/EM SPGT140512-PM/EM SPGT140512-PM/EM SPGT140512-PM/EM SPGT140512-PM/EM SPGT140512-PM/EM SPGT140512-PM/EM
ZTD03-130-XP20-SP05-02 ● 13 ZTD03-140-XP20-SP05-02 ● 14 ZTD03-150-XP20-SP05-02 ● 15 ZTD03-160-XP20-SP05-02 ● 16 ZTD03-170-XP25-SP06-02 ● 17 ZTD03-180-XP25-SP06-02 ● 18 ZTD03-190-XP25-SP06-02 ● 19 ZTD03-200-XP25-SP06-02 ● 20 ZTD03-210-XP25-SP06-02 ● 21 ZTD03-220-XP25-SP06-02 ● 22 ZTD03-230-XP25-SP07-02 ● 23 ZTD03-240-XP25-SP07-02 ● 24 ZTD03-250-XP25-SP07-02 ● 25 ZTD03-260-XP25-SP07-02 ● 26 ZTD03-270-XP25-SP07-02 ● 27 ZTD03-280-XP25-SP07-02 ● 28 ZTD03-290-XP32-SP07-02 ● 29 ZTD03-300-XP32-SP09-02 ● 30 ZTD03-310-XP32-SP09-02 ● 31 ZTD03-320-XP32-SP09-02 ● 32 ZTD03-330-XP32-SP09-02 ● 33 ZTD03-340-XP32-SP09-02 ● 34 ZTD03-350-XP32-SP09-02 ● 35 ZTD03-360-XP32-SP09-02 ● 36 ZTD03-370-XP40-SP11-02 ● 37 ZTD03-380-XP40-SP11-02 ● 38 ZTD03-390-XP40-SP11-02 ● 39 ZTD03-400-XP40-SP11-02 ● 40 ZTD03-410-XP40-SP11-02 ● 41 ZTD03-420-XP40-SP11-02 ● 42 ZTD03-430-XP40-SP11-02 ● 43 ZTD03-440-XP40-SP14-02 ● 44 ZTD03-450-XP40-SP14-02 ● 45 ZTD03-460-XP40-SP14-02 ● 46 ZTD03-470-XP40-SP14-02 ● 47 ZTD03-480-XP40-SP14-02 ● 48 ZTD03-490-XP40-SP14-02 ● 49 ZTD03-500-XP40-SP14-02 ● 50
C
Indexable drills WPS-Bohrer
